Metal Cutting Horizontal Bandsaw [Code: hs0002]

Metal Cutting Horizontal Bandsaw
Description & Specification:

Metal Cutting Horizontal Bandsaw.

SPECIAL FEATURES :   Less power consumption compared to Hacksaw Continuous Cutting by Means of Circular Endless Blade Smoother & Faster Cutting compared to Hacksaw Easy & Precise Gravity Manual Feed Control Makes Optimum use of the blade due to Rewelding of Blade Special Swing cut Operation to cut larger Section Efficient Self Centering Vice Optional Swivel Vice for 30 /45 /60 Angular Cutting Specially Designed heavy duty Gear box Blade Guide Made of Bearing & Carbide Tips Less Material Wastage due to Lesser Blade Thickness Good Parallelism Compared to Hacksaw Machine.

Size 7" 8" 10" 12" 14" 16" 18" 20" 24"
Stroke
(adjustable)
5.5" 5.5" 5.5" 5.5" 5.5" 5.5" 5.5" 5.5" 5.5"
No. of Stroke per min. 100 to 120 100 to 120 85 to 100 85 to 100 75 to 85 75 to 85 60 to 85 60 to 85 60 to 85
Electric Motor Required 1 H.P. 1 H.P. 1.5 H.P. 2 H.P. 2 H.P. 3 H.P. 5 H.P. 7.5 H.P. 7.5 H.P.
R.P.M. 1440 1440 1440 1440 1440 1440 960 960 960
Blade Size 12" to 14" 14" to 16" 16" to 18' 18" to 20" 20" to 22" 22" to 24" 24" to 26" 28" to30" 30" to 32"
Capacity of Round Bar 7" 8" 10" 12" 14" 16" 18" 20" 24"
Capacity of Square Bar 5" 51/2" 8" 10" 11" 13" 14" 15" 18"
