Technical Educational Equipments

We are Technical Educational equipment manufacturers in China with factory and warehouse in China, China Technical Educational Equipments supply company, Manufacturers, Factories, Wholesalers and China Exporters Technical Educational Equipments Supplies China

ELAB Technical Educational Equipments Manufacturer one of the top global manufacturers, suppliers, and exporters of high-quality engineering laboratory equipment, civil and mechanical engineering lab instruments. Technical Educational Equipments Manufacturers, Technical Educational Equipments Exporters in India, Technical Educational Equipments Suppliers, ELAB Engineering Technical Educational Equipments Manufacturers in India, ELAB Engineering Technical Educational Equipments Suppliers in India

Linear Motion Apparatus

Product Code: TEE001 - (Linear Motion Apparatus)

Linear Motion Apparatus....




G-Pendulum Apparatus

Product Code: TEE002 - (G-Pendulum Apparatus)

G-Pendulum Apparatus....




Work Done By A Variable Force Tangential Effort

Product Code: TEE003 - (Work Done By A Variable Force Tangential Effort)

Work Done By A Variable Force Tangential Effort....




Shear Legs Apparatus

Product Code: TEE004 - (Shear Legs Apparatus)

Shear Legs Apparatus Bench top unit for investigation of spatial equilibria of forces, vector addition and resolution, consisting of:   2 push rods, with integrated dynamometer,connectable together with an articulated joint at the top, mounted on a roller slide moveable at the bottom tension chain with integrated dynamometer to be connected with top of the push rods, moveable mounting for other end of tension chain set of weights as load to be connected with hook at top of the pushrods Angles to be adjustable by changing the lengths of the rods and the chain complete with steel base plate. w x d x h:± 1000x565x500mm English operation / instruction manual.....




Crank And Connecting Rod Apparatus

Product Code: TEE005 - (Crank And Connecting Rod Apparatus)

Crank And Connecting Rod Apparatus Bench top unit to explain the function of a crank drive, conversion of rotary motion into oscillatory motion   2 cylinder operation modes possible: fixed cylinder, swivelling cylinder plugs enable the length of the connecting rod and the radius of the crank to be changed by hand, they enable the change from fixed position to swivelling operation crank disk: diameter: 120mm, mounted in ball-bearing, made of anodized aluminium 3 radius settings available: 25, 37.5, 50mm connecting rod material: black, anodized aluminium, adjustable lengths: 120, 140 , 160 mm angle and position of cylinder are measured by scales device fixable on plate with 2 bow-type handles. w x d x h:± 380x280x60mm English operation / instruction manual....




Slotted Link Apparatus

Product Code: TEE06 - (Slotted Link Apparatus)

Slotted Link Apparatus                                                          Harmonic Reciprocating Motion. Bench top unit to generate and investigate a pure harmonic reciprocating motion from an even rotary motion. Plugs enable various crank radii to be changed by hand. Crank disk diameter: 120mm, mounted in ball-bearing, made of anodized aluminum, 3 radius settings available. 25mm, 37.5mm, 50mm. Slider crank material: anodized steel, 3 output strokes: 150m, 75mm, 100mm. Angle and position of slider crank to be measured by scales. Device to be fixed on plate with 2 bow-type handles. w x d x h: ± 380x280x100mm; English operation / instruction manual....




Bench Top Cutaway Model Worm Gear

Product Code: TEE007 - (Bench Top Cutaway Model Worm Gear)

Bench Top Cutaway Model Worm Gear....




Bench Top Cutaway Model Planetary Gear

Product Code: TEE008 - (Bench Top Cutaway Model Planetary Gear)

Bench Top Cutaway Model Planetary Gear....
