Engineering Models Training System

Epicyclic Gear Sun & Planet type

EM15

Epicyclic Gear Sun & Planet Type Engineering Model

Rocker Four Bar Link Mechanism

EM32

A very interesting & properly constructed model to explain the principles of engineering mechanism.

Kinematic Pairs

EM38

All mounted on vertical polished wooden board.

Crank Shaft To Slider Mechanism

EM39

A very interesting & properly constructed model to explain the principles of engineering mechanism.

Scotch Yoke Link Bar Mechanism

EM42

A very interesting & properly constructed model to explain the principles of engineering mechanism.

Inversion of Four Bar Mechanism

EM43

Made of metallic parts with wooden base

Crank Drive To Oscillating Link Mechanism

EM44

A very interesting & properly constructed model to explain the principles of engineering mechanism

Action of Cams

EM47

It is very interesting to demonstrate the functions of four types of Cam  - Heart Shaped, Plate, Involutes and Eccentric.

Hydraulic Break Unit

EM59

Suitably sectioned full size unit. Consisting of original parts

Power Brake Actual Working:

EM63

Working model with actual parts dually painted.

Standard Bolt

EM103

Properly constructed model is of aluminium alloy, complete with whitworth nut, lock nut and washer.

Bolts of Different Types

EM104

Properly constructed and mounted on base with nomenclature.

Locking Arrangement of Bolts

EM107

With the help of these models actual locking systems can be demonstrated.

Link Mechanism

EM33

A very interesting & properly constructed model to explain the principles of engineering mechanism.
