Applied Mechanics Training System

Friction Slide Apparatus

AMLI30

Friction slide apparatus – it is very interesting to study the different law of friction with it comprising of a 75 x 15 cm wooden board and a frictionless pulley at one end a scale pan with the following accessories with weights

Combined Inclined Plane And Friction Slide Apparatus

AMLI33

Consisting of a wooden plane 90 x 18cm having adjustment for setting the required angle precisely.

Combined Coil And Flat Belt Friction Apparatus

AMLI35

It consists of a metallic pulley of 30 cm. diameter with two grooves one for rope and the other for belt.

Combined Coil And �V� Belt Friction Apparatus

AMLI36

It consists of a metallic pulley of 30 cm. diameter with two grooves one for rope and the other for belt.

Combined Coil, Flat And �V� Belt Friction Apparatus

AMLI37

It consists of a metallic pulley of 30 cm. diameter with two grooves one for rope and the other for belt.

Winch Crab Single Purchase

AMLI53

Fitted with heavy cast iron wall brackets. The grooved wheel is of 25 cm diameter and gears are machine cut.

Winch Crab Double Purchase

AMLI54

Fitted with heavy cast iron wall brackets. The grooved wheel is of 25 cm diameter and gears are machine cut.

Compound Screw Jack

AMLI61

Consisting of a jack screw of T. P.I and start carrying load platform.

Compression Of Coiled Springs

AMLI69

Consisting of a cast iron bracket for attaching to wall with sliding and scale.

The Combined Compression And Extension Of Springs Apparatus

AMLI70

The unit is complete with six standard steel springs 20 cm long each of different thickness, three for compression and three for extension.

Hooks Law Apparatus

AMLI71

It consists of a scale mounted vertically on stand, a spring with pointer and provision to hang set of slotted weights.

Youngs Modulus Apparatus (Searles Pattern)

AMLI72

It comprises two metal frames connected by a link mechanism carrying a spirit level.

Youngs Modulus Apparatus (Searles Pattern)

AMLI73

Comprising of two cast iron frames with specially designed self centering chucks

Youngs Modulus Apparatus (Vernier Type)

AMLI74

Simple but very efficient consisting of 10 cm brass scale and vernier to read 0.1 mm with slide.

Tortion Apparatus Searles Type

AMLI79

Horizontal bench pattern. The wheel moving on ball bearing is provided with a chuck to hold the rod under test.

Tortion Apparatus Vertical Type

AMLI80

A steel frame mounted on heavy cast base with leveling screw.

Moment of Inertia of Flywheel

AMLI85

Comprising of carefully machined and balanced cast iron wheel and steel spindle is supported on ball bearings in strong iron brackets.

Moment of Inertia of Flywheel

AMLI86

Comprising of carefully machined and balanced cast iron wheel and steel spindle is supported on ball bearings in strong iron brackets.

Universal Force Table (Superior)

AMLI01

Complete with six sliding clamping pulleys to fix up the same at any desired angle.

Inclined Plane Apparatus (Normal Quality)

AMLI31

The convenience and versatility of this unit has made it very popular.

Inclined Plane Apparatus (Superior Quality)

AMLI32

Consisting of 75 x 20 cm wooden plane with glass top hinged to another base board to which a sector with graduated are and vertical scale is attached.

Universal Force Table (Normal)

AMLI02

Complete with leveling screws, clamping device to fix the table at any desired angle, five sliding clamp pulleys, central ring, string and five sets of iron nickelled  slotted weights, each set  containing nine slotted weights and one hanger of 50 gms each.

Tortion Apparatus(Clamp Pattern)

AMLI78

It is more convenient to observe the tortion produced in rods of varying lengths between 1 meter to 2 meter.
